Additional Information
Key Features
- Seiko SPT Industrial Heads Powered by renowned Seiko SPT printheads (SPT1024 & SPT508) for sharp images, reliability, and extended operational life.
- High-Speed Production Capable of print speeds up to 2800 sqft/hr, ensuring quick turnaround times for high-volume jobs.
- Advanced Heating System Equipped with Pre-heater, Middle Heater, Front Heater, IR Heaters, and Drying Fans for optimal ink curing.
- Nonstop Production Design Built for continuous industrial environments with auto consistent ink supply and single color positive flush cleaning.
- Wide Media Compatibility Handles Banner, Vinyl, Outdoor Media, Photo Paper, PP, and Backlit Film with adjustable carriage height.
Technical Specifications
| Specification | CJ 7304 | CJ 7308 |
|---|---|---|
| Brand | Nuventure | Nuventure |
| Series | CJ 7000 | CJ 7000 |
| Printhead | Seiko SPT1024 – 25pl GS | Seiko SPT508 – 12pl GS |
| No. of Printheads | 4 Pcs | 8 Pcs |
| Printhead Configuration | 1 × 4 | 2 × 4 |
| Max Print Width | 3220 mm | 3220 mm |
| Max Media Width | 3280 mm | 3280 mm |
| High Speed Mode | 480×360 dpi – 2800 sqft/hr | 480×360 dpi – 2400 sqft/hr |
| Standard Speed | 480×540 dpi – 1930 sqft/hr | 480×540 dpi – 1670 sqft/hr |
| High Quality Mode | 480×720 dpi – 1400 sqft/hr | 480×720 dpi – 1200 sqft/hr |
| Ink Type | Solvent Ink | |
| Ink Colors | KCMY | |
| RIP Software | Maintop (PhotoPrint Optional) | |
| Interface | TCP/IP (Ethernet), USB 2.0 | |
| Heating System | Pre-heater, Middle Heater, Front Heater, IR Heaters & Drying Fans | |
| Carriage Height | 2 mm – 5 mm Adjustable | |
| Power Supply | AC 220V, 50/60 Hz | |
| Working Environment | Temp: 22–28°C, Humidity: 40–70% | |
Applications
- Large Format Advertising
- Flex & Vinyl Printing
- Outdoor Banners & Hoardings
- Backlit Film Printing
- PP & Photo Paper Printing
- High-Volume Commercial Printing
