Additional Information
Key Features
- Advanced Ink Circulation The constant high-speed ink stream behind the nozzles removes bubbles and impurities, prevents pigment sedimentation, and allows for automatic recovery from blockages without interrupting production.
- Wide Ink Compatibility Designed to handle a broad spectrum of fluids, including Oil-based, UV, Solvent, and Water-based inks, as well as specialty fluids like varnish, white, and metallic inks.
- Extra Wide Print Width Featuring a 108.3mm print width, the Seiko RC1536 allows for print-bar configurations with fewer heads, simplifying machine design and reducing costs.
- High Productivity & Efficiency Operates at frequencies up to 37kHz with up to 10 levels of greyscale. Low-voltage operation reduces energy consumption and investment costs for driver electronics.
- Versatile Drop Volume Capable of jetting drops ranging from 13pl to 225pl, making it suitable for both fine detail work and high-coverage applications.
Technical Specifications
Seiko RC1536M UV (ICA1536T20)
| Ink Compatibility | Oil and UV Ink |
|---|---|
| Drop Volume Range | 13 to 150 pL |
| Max Productivity (10 Drops) | 1.500 µL/sec |
| Discharge at 25M/min | 85 g/m² |
| Native Nozzle Resolution | 360 npi |
| Active Nozzles | 1536 (4 rows) |
| Jetting Frequency | Up to 37 kHz |
| Grey Levels | Up to 10 |
| Print Width | 108.3 mm |
| Dimensions (W x D x H) | 180.0 x 47.6 x 123.3 mm |
| Weight | > 0.7 kg |
Seiko RC1536L UV (ICA1536T0L)
| Ink Compatibility | Oil and UV Ink |
|---|---|
| Drop Volume Range | 25 to 225 pL |
| Max Productivity (10 Drops) | 2.477 µL/sec |
| Discharge at 25M/min | 85 g/m² |
| Native Nozzle Resolution | 360 npi |
| Active Nozzles | 1536 (4 rows) |
| Jetting Frequency | Up to 37 kHz |
| Grey Levels | Up to 10 |
| Print Width | 108.3 mm |
| Dimensions (W x D x H) | 180.0 x 47.6 x 123.3 mm |
| Weight | > 0.7 kg |
Seiko RC1536M Water Based (ICA1536A20)
| Ink Compatibility | Water Based Ink |
|---|---|
| Drop Volume Range | 13 to 150 pL |
| Max Productivity (10 Drops) | 1.500 µL/sec |
| Discharge at 25M/min | 85 g/m² |
| Native Nozzle Resolution | 360 npi |
| Active Nozzles | 1536 (4 rows) |
| Jetting Frequency | Up to 37 kHz |
| Grey Levels | Up to 10 |
| Print Width | 108.3 mm |
| Dimensions (W x D x H) | 180.0 x 47.6 x 123.3 mm |
| Weight | > 0.7 kg |
Seiko RC1536L Water Based (ICA1536A0L)
| Ink Compatibility | Water Based Ink |
|---|---|
| Drop Volume Range | 25 to 225 pL |
| Max Productivity (10 Drops) | 2.477 µL/sec |
| Discharge at 25M/min | 85 g/m² |
| Native Nozzle Resolution | 360 npi |
| Active Nozzles | 1536 (4 rows) |
| Jetting Frequency | Up to 37 kHz |
| Grey Levels | Up to 10 |
| Print Width | 108.3 mm |
| Dimensions (W x D x H) | 180.0 x 47.6 x 123.3 mm |
| Weight | > 0.7 kg |
General Specifications
| Print Directions | Vertical and Horizontal |
|---|---|
| Ink Inlets / Outlets | 1 / 1 |
| Driving Interface | Parallel Interface |
| Country of Origin | Japan |
Printer Compatibility
The Seiko RC1536 series is trusted by leading printer manufacturers for single-pass applications:
- EFI Nozomi 14000 LED
- EFI Nozomi C18000
- EFI Nozomi C18000 Plus
- Packsize EFI X5 Nozomi
