Additional Information
Key Features
- Flexible Printhead Configuration Supports 2 or 3 Epson XP600 printheads (I1600 optional), allowing for scalable speed and color configurations.
- White & Varnish Capability Configured with CMYK+W+Varnish, enabling stunning 3D effects and vibrant prints on transparent or dark materials.
- High-Speed Output Achieves up to 3 sqm/h in 6-pass mode with 3 heads, ensuring efficient production for small to medium batches.
- Versatile Material Application Prints on AB film for transfer onto glass, plastic, metal, acrylic, wood, ceramic, leather, and more.
- Efficient Curing System Integrated UV curing lamp ensures instant drying for immediate handling and transfer.
Technical Specifications
Printing Configuration
| Model | UVDTF-310 |
|---|---|
| Printhead | 2/3 pcs EPSON XP600 print head (I1600 optional) |
| Max Print Width | 30cm / Custom |
| Print Speed (6 Pass) | 2.5 Sqm/h (2 heads) ; 3 Sqm/h (3 heads) |
| Print Speed (8 Pass) | 1.5 Sqm/h (2 heads); 1.75 Sqm/h (3 heads) |
Ink & Media System
| Ink Type | UV DTF Ink |
|---|---|
| Ink Color | C·M·Y·K.W.Varnish |
| Media Type | AB Film |
| Curing System | UV Curing Lamp |
System & Connectivity
| RIP Software | Maintop / Photoprint |
|---|---|
| Connectivity | Network Cable |
| Power Supply | AC110V±10%, AC220V±10%, 50-60Hz |
Dimensions & Weight
| Machine Dimensions | L1160mm × W650mm × H520mm |
|---|---|
| Packing Dimensions | L1180mm × W770mm × H650mm |
| Net Weight | 110 KG |
| Gross Weight | 130 KG |
Applicable Materials
- Glass
- Plastic
- Metal
- Acrylic
- Wood
- Ceramic
- Paper
- Leather
